WiCeiling OA D4M3-2V, LTE cat.9

WiCeiling OA D4M3-2V is an omnidirectional MIMO 4x4 antenna, working in VV-polarization, it´s desired for LTE cat.9 connections. The antenna can be used for popular LTE bands (42, 43), frequencies 3400-3800 MHz. On the bottom side the WiSpot has the full IP67  installation compartment, where You can easily install an electronic board with LTE modem to get the ready-to-use device powered by PoE (802.3af) - RJ45 waterproof high-quality connector. That antenna is predicted to be installed on the ceiling as the small cell base station antenna.

MIMO 4x4
ABS
DownloadDatasheetWiCeiling OA D4M3-2V, LTE cat.9
Download
Need more information about this product ?
Contact with our
sales manager
Where to buy
Share this product on
Electrical specification
Frequency
3.4 - 3.8 GHz
Gain
2 dBi
VSWR
<1.70, max < 2.00
Beamwidth
360°/16°
Polarization
V
Impedance
50 Ω
Max Input Power
50 W
Lighting Protection
No
DC Ground
No
Mechanic specification
Material
ABS
Outer dimensions
23 x 23 x 4.2 cm
9.06 x 9.06 x 1.65 inch
Connector
4xU.FL
Weight
0.9 kg
Operating temperature
from -20°C to 80°C
from -4°F to 176°F
Systems
  • LTE band - 22, 42, 43, 48, 49, 52
  • WLAN - 3.6 GHz
  • WiMAX - 3.5 GHz
Applications
  • Stadiums, Public Places
  • Hotspot
  • PtM Connections
Plots
  •
  • No plots available for this antenna.
Any information provided by Wireless Instruments Sp. z o.o. is believed to be accurate and reliable. All specifications are subject to change without notice.
